ALUBUBBLE RADIANT BARRIER
Alububble Black Roofing Insulation
Alububble Black is a 4mm bubble foil radiant barrier with a black underside for roof spaces where a darker visible finish is preferred. A standard roll provides 50m² nominal area and approximately 46m² effective coverage with a 100mm overlap.
Air Gaps
air gaps
Product Overview
Alububble Black is a 4mm bubble foil radiant barrier with a black underside. It provides a dark visible finish for suitable roofs where appearance matters, including restaurants, theatres and industrial buildings.
A standard roll provides 50m² nominal area and approximately 46m² effective coverage with a 100mm overlap. Its reflective barrier works with adjacent air spaces; the R1.103 result on the manufacturer's shared data sheet was tested with specified air gaps.
Key Benefits
- ✓Black finish on the visible underside
- ✓Radiant heat barrier for suitable roofs
- ✓46m² effective coverage per roll
- ✓Flexible bubble foil construction
- ✓Suitable where a dark finish is preferred
- ✓Used with adjacent air spaces
- ✓Specified roof and over-purlin applications
- ✓Available for supply by the roll
Typical Application
The black underside gives an appropriately designed roof a discreet, dark finish when viewed from below.
Technical Product Data
Alububble Black Technical Specifications
Black Alububble is the manufacturer's Code 5050 product. Its Black product page links to the shared Alububble test sheet for the White finish and identifies the finish as a colour change.
| Product range | Alububble Insulation |
|---|---|
| Product type | Roofing Insulation |
| Material | Radiant Barrier |
| Manufacturer code | 5050 |
| Nominal thickness | 4mm |
| Standard roll width | 1.25m |
| Standard roll length | Approximately 40m |
| Nominal roll area | 50m² |
| Effective coverage | 46m² with 100mm overlap |
| Referenced R-value | R1.103m²·K/W with specified air gaps |
| Test air gaps | 40mm above and 60mm below |
| Referenced mass | 270g/m² on shared manufacturer data sheet |
| Finish | Black polyethylene underside |
| Fire information | Manufacturer references its White product test for Black |
| Typical application | Specified roofs requiring a black underside |
Roof Insulation Applications
Where Is Alububble Black Used?
The manufacturer recommends Black Alububble where a black finish is preferred, including restaurants and theatres. The roofing contractor should confirm suitability for the specific roof design.
Restaurants
A radiant barrier option when the visible roof underside calls for a darker finish.
View Roof Insulation →
Theatres & Dark Interiors
The black underside offers a less prominent finish when viewed from below.
View Alububble Range →
Commercial Roofs
Suitable where the project specifies a bubble foil radiant barrier with a black visible underside.
View Radiant Barriers →Manufacturer Installation Notes
Alububble Black Installation Guidance
These points summarise the manufacturer's Black product specification and installation guide. Follow the complete instructions for the roof construction being used.
Need Alububble Black Rolls?
Tell us your roof area and the quantity you need. We can help estimate roll coverage and quote for the supply of Alububble Black.
Request a Supply QuoteProduct Documentation
Alububble Data Sheet & Installation Guidelines
View the Alububble data sheet and installation guidelines below. Both PDFs are available directly from Home Insulations.
Alububble Data Sheet
View the Alububble data sheet and technical specifications.
Alububble Installation Guidelines
View the installation guidelines for Alububble roof insulation.
Alububble Black Information
Frequently Asked Questions
The manufacturer's Black product page links to the White product's data sheet, which reports R1.103m²·K/W when tested with a 40mm air gap above and a 60mm air gap below. This is a tested arrangement, not the 4mm material alone.
The shared manufacturer data sheet lists a nominal 50m² roll and 46m² effective coverage with a 100mm overlap. Allow separately for cuts and project waste.
No. Alububble Black has a black polyethylene underside. White Alububble is a separate finish.
The manufacturer says only White Alububble was tested and references that result for Black because the finish differs by colour pigmentation. Request the current documentation for a project requiring formal fire approval.
The manufacturer mentions restaurants and theatres as examples where a black visible roof finish is preferred. The roof design must still be suitable for the product.
No. We supply Alububble Black rolls. Arrange installation with your roofing contractor using the manufacturer's guidance.
